With its extremely wide sound dispersion over 360°, the CONO alto in-ceiling loudspeaker guarantees high-quality and precise sound reproduction.
Get an offer
CONO alto in-ceiling loudspeaker
For high-quality and precise sound reproduction
Built-in loudspeaker for ceiling mounting in an elegant design with maximum sound dispersion.
With its maximum sound dispersion over 360°, the CONO alto in-ceiling loudspeaker is a guarantee for high-quality and precise sound reproduction. It is also characterised by its elegant design: Thanks to its unique appearance, the CONO alto is not recognisable as a conventional loudspeaker. It does not require a grille, which ensures particularly clear and precise sound reproduction. It can also be installed with minimal effort. The insert with a minimum installation depth of 41 mm to 88 mm, depending on the model, is particularly suitable for very low ceiling constructions. The ceiling cut-out is 130 mm.
Technical Data
Built-in speakers for ceiling installation
| Colours | White, black, silver |
| Dimensions | ø 180 mm x 20 mm (in view) |
| Material | Glass fibre reinforced ABS plastic |
| CONO alto 50 | CONO alto M | CONO alto S | CONO alto V | |
|---|---|---|---|---|
| Principle | Full-range 360° | Full-range 360° | Full-range 360° | Full-range 360° |
| Nominal power | 50 W / 90 W | 50 W / 90 W | 100 W / 180 W | 5-10-20 W adjustable |
| Impedance | 16Ω | 4Ω | 8Ω | 100 V / 1,9k - 940 - 470 Ω |
| Efficiency | 83.4 dB | 85.5 dB | 82.8 dB | 86.8 dB |
| Max. SPL | 100 dB | 102 dB | 104 dB | 99.5 dB |
| Frequency range | 89 - 21.000 Hz | 77 - 21.000 Hz | 78 - 21.000 Hz | 86 - 21.000 Hz |
| CONO alto 50 | CONO alto M | CONO alto S | CONO alto V | |
|---|---|---|---|---|
| Weight | 730 g | 830 g | 1.3 kg | 1 kg |
| Ceiling cut-out | 130 mm | 130 mm | 130 mm | 130 mm |
| Installation depth | 41 mm | 74 mm | 77 mm | 88 mm |
| Connections | Block clamp | Print terminal | Gold-plated pole terminal | Print terminal |
